The size and specifications of automotive LED headlight cooling fans vary by brand and model. Common sizes include 3010, 2510, 4020, etc. The specific specifications are as follows:
3010 cooling fan:
Dimensions: 30mm outer diameter, 10mm thick.
Speed: 5500-9500 RPM.
Air volume: 2.45-4.23 CFM.
Bearing type: oil-containing bearings and ball bearings.
Service life: 30000-50000 hours.
2510 cooling fan:
Dimensions: 25mm x 25mm x 10mm.
Speed: 12600 RPM.
Air volume: 2.5 CFM.
Motor power: 0.3W.
Voltage: 5V, 9V, 12V, 24V.
4020 cooling fan:
Dimensions: 40mm x 40mm x 20mm.
Speed: 9000 RPM.
Air volume: 25 CFM.
Motor power: 8W.
Voltage: 12V, 24V.
